mini motorcycle

Quick Details
Product Code：
8711204000
OEM：
Available
Sample:
Available
Port:
shang hai
Payment:
T/T
Place of Origin：
China
Supply Ability：
500 piece per month
Quick Details
  • Color
    red,blue,black
OK
Shipping fee
Shipping fee
Inquiry Basket
Contact Supplier

MB200 is our hot selling off road motorcycle , it is a handsome small chooper with big fun!



MB200 features:

1. equipped with front and rear shock absorber

2. front and foot rest , use the front rest when driving , use the back one when standing. front foot rest is separate with frame less vibration

3. engine is installed with mounting bracket not direct with frame . so less vibration

4. driven by CVT belt. not the chain drive

5. plastic decorative fuel tank with left and right guard bars

6. the rear wheel is installed by rocker arm . not directly be installed on frame

7.with left and right side cover, protect against scalds

8.wide and comfortable seat

9.big round headlight

10.OHV engine big torque

11.widened tires





Overview

Quick Details
Type:
Chopper
Fuel:
Gas / Diesel
Max. Speed:
40 - 60km/h
Certification:
ce
Displacement:
200cc
Engine Type:
4-Stroke
Condition:
New
Place of Origin:
Jiangsu, China
Brake(F/R):
Disc/Disc
Product Name:
4-stroke Dirt Bike
Keywords:
TBM MB200-2
Engine:
4 Stroke Air-cooled
Start:
Electirc Start
Transmission:
Chain Drive
PRODUCT SIZE:
1680*800*980
Tires:
AT19X7-6/AT19X7-8
SEAT HEIGHT:
720mm
Clutch:
auto clutch
Max Load:
95 Kg

Supply Ability
Supply Ability
10000 Carton/Cartons per Month
Packaging & Delivery
Packaging Details
Iron Frame and Carton for two wheels motorcyle moto bike
Port
shanghai port

TBM MB200-2two wheel 196cc Powersports

trail blazer TBM200 storm MX196-2 220cc two wheel Gas powered Mini Bike Kid Gas Dirt Biketrail blazer TBM200 storm MX196-2 220cc two wheel Gas powered Mini Bike Kid Gas Dirt Biketrail blazer TBM200 storm MX196-2 220cc two wheel Gas powered Mini Bike Kid Gas Dirt Bike

MB200 two wheels offroad motorcycle
  model MB200
general information
length 1680
width 800
hight 980
wheelbase 1250
seat hight 720mm
minimum ground clearance 170
max speed 45KM/H
engine information
model JF200
type four stroke
cyclinder qty single cyclinder
cooling method air force cooling
displacement 196CC
bore  68
stroke 54
compression ratio 8.5:1
fuel supply method fuel tank switch direct
carburetor type P19
power 3.68KW/3600rpm
torque 13.5N.m/2500rpm
ignition mode Transistor contactless ignition
starting mode hand pull start
lubrication mode splash
spark plug model  F7RTC
spark plug clearance 0.7-0.8mm
crankcase lubricating oil SAE 10W/40
fuel type gasoline,≥92
fuel tank capacity 3.6L
transmission CVT
other information
clutch auto clutch
fuel 15A
front wheel type AT19X7-6
rear wheel type AT19X7-8
brake mode  disc brake
driven mode rear wheel
tire pressure  80-100kpa
climb ability 15°
 net weight 76Kg
gross weight 91Kg
max load 95Kg
container loading qty 111 unit
packing size 1500*450*760mm


1. Q May I get some samples?

A: We are honored to offer you samples for quality and performance confirming.



2. Q: Do you have the products ready for shipment ?

A: No. All vehicles are to be produced according to your order..



3. Q: how long is the delivery time?

A:normally 25 working days to produce an order from MOQ to 40HQ container..



4. Q: is it possible to mix different models in one container?

A: Yes, different models can be mixed in one container.



5. Q: How does your factory do regarding quality control?

A: we start quality control from beginning to end of production .first parts inspection ,then assemble checking , and final adjusting and testing., each products will be carefully checked . we are manufacture and we have final responsible for our products quality .
