go kart buggy k5 plus

Quick Details

Product Code：

8703101100

OEM：

Available

Sample:

Available

Port:

shang hai

Payment:

T/T

Place of Origin：

China

Supply Ability：

300 piece per month

Quick Details

color

red,blue.green

Shipping fee

Inquiry Basket

Contact Supplier

1.right hand drive (RHD) is optional

2.rear Four-points mounting one axle independent suspension. flexible left and right side anti-slip pull belts are equipped.

3. play drift freely throw slide never roll over

4.more spacious cockpit than the competition.

5.LED headlight combined with flowing turning light

6.Three-point anti-impact seat belt like car safe belt

7.150cc, 175cc,200cc,300cc Engines available for age range, with reverse as standard, engine technology is mature and reliable, parts are readily available everywhere

8.longer front swim arm

9.seat adjustable

10.stylish plastic cover

11.high back seat

12.foam padded bars

13.Adjustable steering wheel

14.Combined control panel

15.Soft cable shift handle

16.could be driven through river crossing with water 20cm deep in it and ran it over.

17.Brake holder parking

Overview

Quick Details

Place of Origin:: Jiangsu, China

Model Number:: k7 k7 plus off road go kart

Certification:: ce

Engine:: 300cc GY6 water cooled, 4 stroke, with CVT gear

Drive Mode:: chain drive

Wheel Size:: 22*7-10 /22*10-10/23/10.5-12

Oil Tank Capacity:: 11L

Maximum Speed:: 65KM

Displacement:: 300CC

Brake Type:: Disk brake

Engine Capacity:: 201-500cc

Product name:: off road k7 k7 plus

Brake:: Hydraulic Disc Brake

All terrain roads:: Grassland...etc

Frame:: Strong Steel

Dimensions:: 2340*1400*1530mm

Transmission:: CVT F-N-R

Engine type:: 4 Stoke

Weelbase:: 1800 MM

Net weight:: 280 KGS

Fit for:: Quad

Combo Set Offered:: 0

Supply Ability

Supply Ability: 400 Carton/Cartons per Month

Packaging & Delivery

Packaging Details: Iron Frame and Carton for go cart

Port

shanghai port

ENGINE INFORMATION:
EPA certificated EPA USA / CANADA MARKET
Engine type	173MN, 4-STROKE,SINGLE CYLINDER,WATER COOLED
Displacement	275.6CC
Output Max.	13KW/6500RPM
Max torque	22Nm/5000RPM
Bore x stroke	INCHES (72.5 X 66.8 MM)
Max speed	60KM/H
Climbing ability	15°
Ignition	C.D.I
Starting system	ELECTRIC START
Battery	YTX12-BS 12V10AH
Carburetor Item	Y28V1L
Engine oil	SAE 10W/40
General Information
Clutch	AUTOMATIC CVT
Gears	D-N-R
Driveline / Driving wheel	CHAIN / DUAL WHEEL DRIVE
Suspension, F / R	DUAL A-ARM / THRU-SHAFT WITH DUAL SHOCKS AND DUAL A-ARM
Brakes, F / R	DISC
Tires, F / R	227-10 /2210-10
Fuel capacity	2.25 GAL (8.516L)
Weight, G.W. / N.W.	330 KGS/280 KGS
Max load	599 LBS (247)
Dimension Information
Wheelbase	1800 MM
OA L x W x H	234014001530mm
Height to seat	470 MM
Min. ground clearance	150 MM
Pedal to seat back	920-1060 MM
Shipping information	30UNITS / 40HQ
package size	23001200860 MM

2020 newest GAS go kart EPA CARB k3 k5 k5 plus k7 right hand drive RHD

1. Q May I get some samples?

A: We are honored to offer you samples for quality and performance confirming.

2. Q: Do you have the products ready for shipment ?

A: No. All vehicles are to be produced according to your order..

3. Q: how long is the delivery time?

A:normally 25 working days to produce an order from MOQ to 40HQ container..

4. Q: is it possible to mix different models in one container?

A: Yes, different models can be mixed in one container.

5. Q: How does your factory do regarding quality control?

A: we start quality control from beginning to end of production .first parts inspection ,then assemble checking , and final adjusting and testing., each products will be carefully checked . we are manufacture and we have final responsible for our products quality .
