go kart buggy K5

1.right hand drive (RHD) is optional

2.rear Four-points mounting one axle independent suspension. flexible left and right side anti-slip pull belts are equipped.

3. play drift freely throw slide never roll over

4.more spacious cockpit than the competition.

5.LED headlight combined with flowing turning light

6.Three-point anti-impact seat belt like car safe belt

7.150cc, 175cc,200cc,300cc Engines available for age range, with reverse as standard, engine technology is mature and reliable, parts are readily available everywhere

8.longer front swim arm

9.seat adjustable

10.stylish plastic cover

11.high back seat

12.foam padded bars

13.Adjustable steering wheel

14.Combined control panel

15.Soft cable shift handle

16.could be driven through river crossing with water 20cm deep in it and ran it over.

17.Brake holder parking





Overview

Quick Details

Place of Origin:   Jiangsu, China                        Model Number: TBM GO KART K5-1

Certification: ce                                               Engine: 150cc 175cc

Drive Mode: automatic CVT                               Wheel Size: 22*7-10/22*10-10

Oil Tank Capacity: 10L                                       Maximum Speed: 60KM

Displacement: 175cc                                         Brake Type: disk

Engine Capacity: 50-200CC                              Product name: go kart buggy

Transmission: chain                                          keywords: gas buggy

Size: 2340*1400*1480                                       Max speed: 65km/h

Frame: Strong Steel                                          Brake: Hydraulic Disc Rear

Model Name: K5                                              Weelbase: 1800

Transmission mode: CVT                                   Combo Set Offered: 0



Supply Ability

Supply Ability        1000 Carton/Cartons per Month



Packaging & Delivery

Packaging Details          Iron Frame and Carton for go cart

Port                             shanghai port

TBM GO KART K5-1gas buggy

ENGINE INFORMATION:
EPA certificated  EPA  USA / CANADA MARKET CE certificate for European market
Engine type	GY6 TYPE JL1P57F, 4-STROKE,SINGLE CYLINDER,AIR COOLED         JL1P57F
Displacement	149.6 CC
Output Max.	10HP/7500RPM
Max torque	13NM/5000RPM
Bore x stroke	2.26 x 2.28 INCHES  (57.4x57.8MM)
Max speed	60KM/H
Climbing ability	12°
Ignition	C.D.I.
Starting system	ELECTRIC START
Battery	YTX12-BS 12V10AH
Carburetor Item	PD24J
Engine oil	SAE 10W/40
General Information
Clutch	AUTOMATIC CVT
Gears	D-N-R,WITH REVERSE
Driveline / Driving wheel	CHAIN / DUAL WHEEL DRIVE
Suspension, F / R	DUAL A-ARM /  THRU-SHAFT WITH DUAL SHOCKS AND DUAL A-ARM
Brakes, F / R	DISC
Tires, F / R	22*7-10 /22*10-10
Fuel capacity	2.6 GAS (10L)
Weight, G.W. / N.W.	295 KGS/240 KGS
Max load	500 LBS  (227KGS)
Dimension Information
Wheelbase	1800 MM
OA L x W x H	2340*1400*1480 MM
Height to seat	470 MM
Min. ground clearance	150 MM
Pedal to seat back	920-1060 MM
Shipping information	40UNITS / 40HQ
package size	2300*1200*660mm



1. Q May I get some samples?

A: We are honored to offer you samples for quality and performance confirming.



2. Q: Do you have the products ready for shipment ?

A: No. All vehicles are to be produced according to your order..



3. Q: how long is the delivery time?

A:normally 25 working days to produce an order from MOQ to 40HQ container..



4. Q: is it possible to mix different models in one container?

A: Yes, different models can be mixed in one container.



5. Q: How does your factory do regarding quality control?



A: we start quality control from beginning to end of production .first parts inspection ,then assemble checking , and final adjusting and testing., each products will be carefully checked . we are manufacture and we have final responsible for our products quality .
