engine for UTV SIDE BY SIDE SSV ATV QUAD
| model UTV |
UTV300(two seats) |
UTV150 (two seats) |
| Vehicle parameters |
|
|
| length |
2600mm |
2600mm |
| width |
1260mm |
1260mm |
| hight |
1600mm |
1600mm |
| wheel base |
1830mm |
1830mm |
| front wheel center distance |
1080mm |
1080mm |
| rear wheel center distance |
985mm |
985mm |
| Minimum ground clearance |
160mm |
160mm |
| max speed |
65KM/H |
60KM/H |
| net weight |
300KG |
280KG |
| packing size |
2300*1330*880 |
2300*1330*880 |
| engine parameters |
|
|
| engine model |
173MN |
JL1P57F |
| engine type |
four stroke |
four stroke |
| cylinder qty |
single cyclinder |
single cyclinder |
| cooling method |
water cool |
force air cool |
| displacement |
275.6cc |
149.6cc |
| bore |
72.5 |
57.4 |
| stroke |
66.8 |
57.8 |
| compression ratio |
10:1 |
9.2:1 |
| fuel supply mode |
External electronic oil pump |
Negative pressure oil pump |
| carburetor type |
Y28V1L |
PD24J |
| power |
13KW/6500RPM |
7.4KW/7500RPM |
| torque |
22Nm/5000RPM |
13Nm/5000RPM |
| ignition mode |
battery ignition |
battery ignition |
| lubrication mode |
splash |
splash |
| spark plug model |
DR8EA |
C7HSA |
| spark plug clearance |
0.6-08mm |
0.6-07mm |
| crankcase lubrication oil model |
SAE 10W/40 |
SAE 10W/40 |
| fuel number |
gasoline ≥92# |
gasoline ≥92# |
| transmission mode |
continuously variable speed CVT |
continuously variable speed CVT |
| transmission |
built in reverse |
built in reverse |
| other parameters |
|
|
| battery model |
YTX12-BS 12V10Ah |
YTX12-BS 12V10Ah |
| fuse |
30A |
30A |
| front wheel model |
22*7-10 |
22*7-10 |
| rear wheel model |
22*10-10 |
22*10-10 |
| brake type |
hydraulic disk brake |
hydraulic disk brake |
| front suspension type |
double A arm independent suspension |
double A arm independent suspension |
| rear suspension type |
independent suspension |
rear axle with double shockabsorber |
| driven type |
rear wheel driven |
rear wheel drive |
| tyre pressure |
80-100kpa |
80-100kpa |
1. Q May I get some samples?
A: We are honored to offer you samples for quality and performance confirming.
2. Q: Do you have the products ready for shipment ?
A: No. All vehicles are to be produced according to your order..
3. Q: how long is the delivery time?
A:normally 25 working days to produce an order from MOQ to 40HQ container..
4. Q: is it possible to mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q: How does your factory do regarding quality control?
A: we start quality control from beginning to end of production .first parts inspection ,then assemble checking , and final adjusting and testing., each products will be carefully checked . we are manufacture and we have final responsible for our products quality .
