KID MINI size go kart GKXRX-copy
- colorred,green,blue, PINK
| Trail blazer Mini XRX+ Go Kart | |
| technical specification | |
| Engine type | 4-stroke, single cylinder, air cooled |
| Displacement | 163cc |
| Max HP | 5.5hp/3600rpm |
| Max torque | 8 lb ft/3600rpm |
| Bore x stroke | 2.6 x 1.8 inches |
| Climbing ability | 12 degrees |
| Ignition | C.D.I |
| Starting system | Electric Start with Pull Start Backup |
| Battery | 12V 9Ah |
| Carburetor brand | JF (RX) |
| Engine oil | SAE 15W-40 |
| Transmission | Fully Automatic Transmission |
| Driveline / Driving wheel | Chain / Dual wheel drive |
| Suspension, F / R | Dual A-arm / Double Oil Damped Shock |
| Brakes | Disc |
| Tires, F / R | 145X70-6 / 16 X8-7 |
| Fuel capacity | 1.2 gal |
| Weight, G.W. / N.W. | 280 / 232 lbs |
| Max load | 300 lbs |
| Dimension Information | |
| Wheelbase | 42.6 inches |
| OA L x W x H | 58.7 x 38.2 x 48.8 inches |
| Height to seat | 13.6 inches |
| Min ground clearance | 4.02 inches |
| Pedal to center seatback | 30"""" to 35""""; Pedal can also adjust to 3"""" or 6"""" shorter. |
| Main Features | Live Axle, Two-wheel Drive, Electric Start w/Pull Start Back Up, LED Headlight, Remote Start/Kill, Adjustable Sports Seat, Adjustable Pedal, Five-Point Safety Seatbelt, Speed Governor, Horn" |
| Notes | "EPA certified and CARB approved |
BEST QUALITY KIDS KART WITH BIG TIRES AND LARGER FRAME!!
Main Features: Bigger Tires, Larger Frame, Live Axle, Two-wheel Drive, Electric Start w/Pull Start Back Up, LED Headlight, Remote Start/Kill, Adjustable Sports Seat, Adjustable Pedal, Five Point Safety Seatbelt, Speed Governor, Horn
Packaging Details
Iron Frame and Carton for go cart
double seat, full suspension Go Kart powered by a 163cc, 5.5 hp Engine and features 2-wheel drive and centrifugal clutch.
1. Q May I get some samples?
A: We are honored to offer you samples for quality and performance confirming.
2. Q: Do you have the products ready for shipment ?
A: No. All vehicles are to be produced according to your order..
3. Q: how long is the delivery time?
A:normally 25 working days to produce an order from MOQ to 40HQ container..
4. Q: is it possible to mix different models in one container?
A: Yes, different models can be mixed in one container.
5. Q: How does your factory do regarding quality control?
A: we start quality control from beginning to end of production .first parts inspection ,then assemble checking , and final adjusting and testing., each products will be carefully checked . we are manufacture and we have final responsible for our products quality .
